Model型號 | AEV-203 | AEV-210 | AEV-232 | AEV-260 | AEV-320 | AEV-340 | AEV-360 | AEV-420 | AEV-440 | AEV-460 |
激振器型號Vibration model | VG300/40 | VG1000/50 | VG3200/50 | VG6000/50 | VG2200/76 | VG4000/76 | VG6000/76 | VG2000/100 | VG4000/100 | VG6000/100 |
頻率范圍(HZ) Frequency range | 1-2500 | 1-3000 | 1-3000 | 1-2700 | 1-3000 | 1-2700 | 1-2500 | 1-3000 | 1-2500 | 1-2500 |
最大激振力Kg(KN) Max sine Force | 300(2.94) | 1000(9.8) | 3200(31.36) | 6000(58.8) | 2000(19.6) | 4000(39.2) | 6000(58.8) | 2000(19.6) | 4000(39.2) | 6000(58.8) |
最大位移mm(p-p) Max Displacement | 40 | 50.8 | 50.8 | 50.8 | 76.2 | 76.2 | 76.2 | 101.6 | 101.6 | 101.6 |
最大加速度(g) Max Acceleration | 100 | 100 | 100 | 100 | 80 | 100 | 100 | 66 | 100 | 100 |
最大速度(cm/s) Max Velocity | 200 | 200 | 200 | 200 | 200 | 200 | 200 | 200 | 250 | 200 |
有效載荷(kg) Max Load | 120 | 200 | 400 | 1000 | 300 | 500 | 1000 | 300 | 500 | 1000 |
動圈質(zhì)量(kg) Armature Weight | 3 | 10 | 32 | 50 | 25 | 35 | 55 | 30 | 35 | 60 |
動圈直徑(mm) Armature Diameter | ¢150 | ¢240 | ¢400 | ¢445 | ¢320 | ¢440 | ¢445 | ¢320 | ¢445 | ¢445 |
激振器重量(kg) Shaker Weight | 460 | 1100 | 2500 | 4500 | 1700 | 3500 | 4500 | 1700 | 3500 | 4500 |
激振器尺寸(mm) Shaker Dimensions (L×W×H) | 750×560×670 | 845×685×840 | 1270×980×1140 | 1650×1150×1280 | 1200×870×1130 | 1650×1150×1280 | 1650×1150×1280 | 1200×870×1130 | 1650×1150×1280 | 1650×1150×1280 |
功率放大器型號 Power Amplifier Model | Amp3K | Amp12K | Amp35K | Amp70K | Amp30K | Amp50K | Amp70K | Amp22K | Amp60K | Amp70K |
功率放大器重量(kg) Power Amplifier Weight | 250 | 350 | 550 | 1000 | 550 | 800 | 1000 | 550 | 800 | 900 |
冷卻方式Cooling Method | 強制風冷Forced air cooling |
功率放大器尺寸(mm) Power amplifier size (L×W×H) | 880×580×1150 | 880×580×1690 | 910×620×1550 | 910×620×2000 | 880×580×1520 | 910×620×2000 | 910×620×2000 | 910×620×2000 | 910×620×2000 | 910×620×2000 |
電源Power supply | AC3¢380V; ±10% 50Hz |
總功率(KW) Aggregate Capacity | 9 | 25 | 56 | 75 | 40 | 75 | 75 | 45 | 75 | 75 |
